SE Bikes Killer Quad 27.5-inch
This item is currently not available.
Details
Now this is one KILLER ride! The all-new 27.5” Killer Quad is perfection on wheels. This bike has everything you’d want and more. It is built around a unique Quad frame design featuring an oversized downtube, integrated headset, super stiff BB yoke, and a legendary looptail rear end. It comes equipped with a microSHIFT XLE 1x10 drivetrain, Tektro hydraulic disc brakes, and wide 27.5” x 2.5” Vee Speedster tires. When you want to go for a killer ride, this is definitely the bike to have.
| Top Tube, Actual | 22.8" |
|---|---|
| Seat Tube, Center To Top | 15.7" |
| Seat Tube Angle | 73° |
| Head Tube Angle | 71° |
| Chainstay Length | 17.4" |
| Wheelbase | 42.3" |
| Bottom Bracket Height | 11.9" |
| Standover | 28.2" |
| Stem | 55mm |
| Handlebar Width | 31" |
| Crank | 175mm |
| Wheel Size | 27.5" |
| Seat Post Diameter | 27.2mm |
Specs
| Frame | 6061 Aluminum, Single Downtube Killer Quad Design, Internally-machined Integrated Head Tube, Looptail Rear End, Fixed Dropouts, 73mm Euro Bottom Bracket, 135mm Spaced Dropouts, Disc Brake Tabs, Removable Derailleur Hanger |
|---|---|
| Fork | Landing Gear, Full Cr-Mo, 419mm Axle to Crown, 29mm Offset, 110mm Spaced Dropouts |
| Wheels | Sealed Bearing Alloy 36H Nutted Hubs, 135mm Rear Hub, 110mm Front Hub, Double-wall Rims, 11-32T 10-speed Cassette, Stainless Spokes |
| Tires | Vee Tire Co x SE Racing Speedster, 72TPI, 27.5" x 2.5" Front & Rear |
| Crankset | SE Racing 175mm Forged Alloy 2-pc Cranks, Pedal Boss Inserts, External Sealed Euro Bottom Bracket, 24mm Hollow Alloy Spindle, 32T Alloy Chainring |
| Shifters | MicroShift XLE Xpress SL-M850-R, 1x10, Sealed Bearing, Alloy Lever |
| Rear Derailleur | MicroShift XLE RD-M61S, 1x10, Short Cage |
| Cassette/Freewheel | MicroShift XLE CS-H100, 10-speed, 11-32T |
| Chain | KMC S1 |
| Brakes | Tektro HD-M285, Hydraulic Disc, Easy to Adjust Open System, Dual Piston, Automatic Caliper Positioning, 180mm Front Rotor, 160mm Rear Rotor |
| Brake Levers | Tektro HD-M285, 2-Finger Alloy, Front & Rear |
| Handlebars | Big Honkin' Cr-Mo Cruiser Bar, 31" x 7", 12° Backsweep, 2° Upsweep |
| Tape/Grips | SE Racing Flangeless Mushroom Wing Grips w/ SE Rubber End Plugs |
| Stem | Retro Alloy Top-Load w/ Engraved SE Logo on Top & Sides, 55mm Reach |
| Headset | FSA Integrated Orbit CE, Sealed 1-1/8" |
| Seatpost | Micro-Adjust Alloy, 27.2mm |
| Saddle | SE Flyer Seat w/ Custom SE Bottle Opener Brace |
| Pedals | X-Pedo Low-profile Platform w/ Removable Pins |
* Subject to change without notice.
